High Efficiency Drum Coupling
Standard
Anodizing
Stainless Steel Aluminum Steel
1. High Transmission Efficiency Can Reach 99.7%
2. High Loading Capacity: With the same external dimension, the loading capacity is 15%~20% averagely higher than that of straight-tooth coupling
3. Large Angular Compensation: The maximum allowable angular misalignment is 1.5°, 50% higher than that of straight-tooth coupling
4. More Scientific Gear Tooth Design: It avoids local stress concentration caused by straight tooth edge extrusion, and tooth surface friction is eased at the same time.
5. Gear tooth of external gear sleeve is horn-shaped, which makes it easy to install and dismantle.
6. Long Service Life: The internal and external gear teeth are made of high strength alloy steel.
- After quenched-tempered heat treatment, gear teeth rigidity and wear resistance are improved.
- Small dimension, low weight, high transmitted torqueElastomers made of polyurethane with shore hardness between 80-98
- Compensating the axial relative drift, buffer and vibration reduction
- Bore diameter tolerance ISO standard H7
- Material: Aluminium,steel,metal,plastic,etc
- Finishing: blacken, phosphate-coat, and oxidation
Sketch:
| Type | Allowable speed | Shaft hole diameter | Shaft hole length | Grease consumption | Weight | Rotary interia |
| Tn | {n} | L | ||||
| KN.m | r/min | d1,d2,dz | y,J1,Z1 | kg | kg.m² | |
| GCLD1 | 4000 | 22~26 | 35~112 | 107 | 9.6 | 0.0118 |
| GCLD2 | 4000 | 28~65 | 60~142 | 137 | 16.4 | 0.0215 |
| GCLD3 | 4000 | 40~75 | 84~142 | 201 | 22.4 | 0.0475 |
| GCLD4 | 4000 | 45~90 | 84~172 | 238 | 35.6 | 0.095 |
| GCLD5 | 3750 | 50~105 | 84~212 | 298 | 53.9 | 0.168 |
| GCLD6 | 3300 | 55~115 | 84~212 | 465 | 67.5 | 0.268 |
| GCLD7 | 3000 | 60~135 | 107~252 | 561 | 106.7 | 0.528 |
| GCLD8 | 2650 | 65~150 | 107~252 | 734 | 123 | 0.813 |
| GCLD9 | 2350 | 70~175 | 107~302 | 956 | 212 | 1.77 |
| GCLD10 | 2100 | 75~200 | 107~352 | 1320 | 319 | 3.432 |
1. High Transmission Efficiency Can Reach 99.7%
2. High Loading Capacity: With the same external dimension, the loading capacity is 15%~20% averagely higher than that of straight-tooth coupling
3. Large Angular Compensation: The maximum allowable angular misalignment is 1.5°, 50% higher than that of straight-tooth coupling
4. More Scientific Gear Tooth Design: It avoids local stress concentration caused by straight tooth edge extrusion, and tooth surface friction is eased at the same time.
5. Gear tooth of external gear sleeve is horn-shaped, which makes it easy to install and dismantle.
6. Long Service Life: The internal and external gear teeth are made of high strength alloy steel.
- After quenched-tempered heat treatment, gear teeth rigidity and wear resistance are improved.
- Small dimension, low weight, high transmitted torqueElastomers made of polyurethane with shore hardness between 80-98
- Compensating the axial relative drift, buffer and vibration reduction
- Bore diameter tolerance ISO standard H7
- Material: Aluminium,steel,metal,plastic,etc
- Finishing: blacken, phosphate-coat, and oxidation
Sketch:
| Type | Allowable speed | Shaft hole diameter | Shaft hole length | Grease consumption | Weight | Rotary interia |
| Tn | {n} | L | ||||
| KN.m | r/min | d1,d2,dz | y,J1,Z1 | kg | kg.m² | |
| GCLD1 | 4000 | 22~26 | 35~112 | 107 | 9.6 | 0.0118 |
| GCLD2 | 4000 | 28~65 | 60~142 | 137 | 16.4 | 0.0215 |
| GCLD3 | 4000 | 40~75 | 84~142 | 201 | 22.4 | 0.0475 |
| GCLD4 | 4000 | 45~90 | 84~172 | 238 | 35.6 | 0.095 |
| GCLD5 | 3750 | 50~105 | 84~212 | 298 | 53.9 | 0.168 |
| GCLD6 | 3300 | 55~115 | 84~212 | 465 | 67.5 | 0.268 |
| GCLD7 | 3000 | 60~135 | 107~252 | 561 | 106.7 | 0.528 |
| GCLD8 | 2650 | 65~150 | 107~252 | 734 | 123 | 0.813 |
| GCLD9 | 2350 | 70~175 | 107~302 | 956 | 212 | 1.77 |
| GCLD10 | 2100 | 75~200 | 107~352 | 1320 | 319 | 3.432 |
